What Is Live Virtual Machine Lab 7.2 Module 07?

In plain English, this lab is a sandbox that lets you practice configuring Layer 2 switching inside a fully virtualized environment. Think of it as a miniature data center that lives entirely on your laptop or workstation Practical, not theoretical..

The “live” part means the VMs stay powered on while you change settings—no reboot‑and‑wait cycles. The lab ships with a pre‑built topology: a couple of Cisco‑style virtual switches, a few end‑device VMs (PC‑01, PC‑02, etc.), and a management VM that runs the CLI you’ll be typing into.

The Core Components

  • vSwitch0 / vSwitch1 – software‑based switches that mimic Cisco Catalyst behavior.
  • VMs acting as hosts – usually Windows 10 or Linux machines that you’ll assign to different VLANs.
  • Management console – often a Cisco‑like IOSv image where you type enable, configure terminal, and so on.
  • Hypervisor – typically VMware Workstation/Player or VirtualBox; the lab’s .ova/.ovf file expects one of these.

All of that runs on a single physical host, so you can experiment with trunking, port‑security, STP, and even QoS without breaking any production network.

Why It Matters / Why People Care

You might wonder, “Why bother with a virtual switch when I can just click a button in the hypervisor?” The answer is twofold.

First, the concepts you practice here map directly to physical gear. Configuring a trunk port on vSwitch0 is the same syntax you’ll use on a real Cisco 2960. If you nail the lab, you’ll feel comfortable walking into a data‑center rack and typing the same commands on a metal box It's one of those things that adds up..

Second, the “live” aspect mirrors the reality of modern networks. That said, you can’t always take a switch offline to add a VLAN; you have to make changes on the fly while traffic keeps flowing. The lab forces you to think about impact, verify with show commands, and roll back if something goes sideways.

In practice, mastering these switching features reduces downtime, improves security (think port‑security and DHCP snooping), and gives you the confidence to design scalable VLAN architectures Not complicated — just consistent..

How It Works (or How to Do It)

Below is a step‑by‑step walkthrough of the most common tasks in Module 07. I’ve stripped out the fluff and kept the commands you’ll actually type.

1. Access the Management VM

  1. Power on the lab and open the console for the Switch‑Mgmt VM.
  2. Log in with the default credentials (usually cisco/cisco).
  3. Enter privileged mode:
Switch> enable
Switch#

If you’re using a hypervisor that supports “drag‑and‑drop” of a console window, keep that open—switching between VMs is a lot faster.

2. Verify the Existing Topology

Before you touch anything, get a feel for the current layout:

Switch# show vlan brief
Switch# show interfaces status
Switch# show spanning-tree

You’ll see two VLANs already: VLAN 1 (default) and VLAN 10 (the lab’s “Sales” network). Ports Gig0/1 and Gig0/2 are in access mode on VLAN 10, while Gig0/3 is a trunk heading toward the other virtual switch.

3. Create a New VLAN

The lab asks you to add a “Guest” VLAN (VLAN 20). Here’s the quick way:

Switch# configure terminal
Enter configuration commands, one per line.  End with CNTL/Z.
Switch(config)# vlan 20
Switch(config-vlan)# name Guest
Switch(config-vlan)# exit

Don’t forget to save the config later; otherwise the change disappears when the VM reboots Not complicated — just consistent..

4. Assign Ports to the New VLAN

You’ll have two host VMs that need to join the Guest network. Suppose they’re plugged into Gig0/4 and Gig0/5 Most people skip this — try not to. But it adds up..

Switch(config)# interface range Gig0/4 - 5
Switch(config-if-range)# switchport mode access
Switch(config-if-range)# switchport access vlan 20
Switch(config-if-range)# exit

A quick sanity check:

Switch# show vlan brief | include 20

You should see the two ports listed under VLAN 20.

5. Configure a Trunk Between Switches

The lab environment includes a second virtual switch (vSwitch1). To carry multiple VLANs across, you need a trunk on Gig0/3 That alone is useful..

Switch(config)# interface Gig0/3
Switch(config-if)# switchport mode trunk
Switch(config-if)# switchport trunk allowed vlan 1,10,20
Switch(config-if)# exit

If you forget the allowed vlan line, the trunk will default to all VLANs, which is fine for a lab but not best practice in production Less friction, more output..

6. Enable Spanning Tree Protocol (STP)

Even in a tiny lab, STP prevents loops if you accidentally connect two trunks together. Turn it on and verify the root bridge:

Switch(config)# spanning-tree mode rapid-pvst
Switch(config)# exit
Switch# show spanning-tree

You’ll see the local switch elected as the root (priority 32768). In a larger design you’d tweak the priority to control which device becomes root No workaround needed..

7. Set Up Port‑Security

Security often trips people up because the default is “no security.” Here’s a simple MAC‑address limiting on the Guest ports:

Switch(config)# interface range Gig0/4 - 5
Switch(config-if-range)# switchport port-security
Switch(config-if-range)# switchport port-security maximum 2
Switch(config-if-range)# switchport port-security violation restrict
Switch(config-if-range)# switchport port-security mac-address sticky
Switch(config-if-range)# exit

Now the switch will learn up to two MAC addresses on each port, store them in the running config, and simply drop any extra frames That alone is useful..

8. Verify Connectivity

Open a console on one of the Guest VMs, assign an IP in the 192.0/24 subnet, and ping the other Guest VM. Also, 20. 168.If you get replies, you’ve successfully wired the new VLAN Not complicated — just consistent. Which is the point..

PC01> ipconfig /renew
PC02> ping 192.168.20.2

If the ping fails, double‑check that the VM’s NIC is attached to the correct virtual switch port and that the VLAN ID matches And that's really what it comes down to..

9. Save the Configuration

Never leave a lab without persisting your work:

Switch# write memory
Building configuration...
[OK]

If you skip this step, the next time you power on the lab you’ll have to redo everything—an avoidable pain.

Common Mistakes / What Most People Get Wrong

  • Forgetting to set the port mode to access – It’s easy to assume a port is automatically an access port, but the default on many virtual switches is “dynamic desirable,” which can cause the port to negotiate a trunk you didn’t intend.
  • Leaving the trunk allowed‑vlan list empty – By default the trunk will carry all VLANs, which is fine for a sandbox but can mask configuration errors. Always specify the exact VLANs you need.
  • Not enabling STP – In a lab you might think loops are harmless, but they can cause a broadcast storm that stalls the entire VM host. A single stray cable can bring everything down.
  • Skipping the “sticky” MAC command – Without it, port‑security won’t remember the learned MACs after a reboot, forcing you to re‑learn or manually add them each time.
  • Saving the config too early – If you hit write memory before finishing all steps, you’ll lock yourself into a half‑finished state. The habit I recommend: finish all changes, verify with show run, then save.

Practical Tips / What Actually Works

  • Use the console log – Most hypervisors let you capture the console output to a text file. Paste the show commands there; it makes post‑lab documentation painless.
  • apply “show mac address-table” – After you configure port‑security, this command instantly shows which MACs the switch learned. It’s a quick sanity check before you start pinging.
  • Test with a packet sniffer – If you have Wireshark installed on the host, attach it to the virtual NIC of the management VM. You’ll see the 802.1Q tags in real time, confirming that your trunk really is tagging frames.
  • Create a backup of the .ova – Before you start tinkering, clone the original lab file. If something goes catastrophically wrong (like a mis‑configured loop that freezes the hypervisor), you can spin up a fresh copy in seconds.
  • Document the VLAN map – Even in a lab, a simple table (VLAN ID → Purpose → Ports) saves you from hunting through show vlan output later.

FAQ

Q: Do I need a physical switch to complete this lab?
A: No. All switching is virtualized inside the lab’s VMs. The only hardware you need is the machine running the hypervisor Easy to understand, harder to ignore..

Q: My VM can’t ping other VMs even though they’re on the same VLAN. What’s wrong?
A: Check that the NICs are attached to the correct virtual switch port and that the VLAN IDs match on both ends. Also verify that the VM’s firewall isn’t blocking ICMP.

Q: Can I use this lab to practice QoS or LACP?
A: The basic Lab 7.2 image only includes Layer 2 features. Some advanced labs ship separate images with QoS or LACP support—look for “Lab 7.2‑Advanced” in the download folder.

Q: Why does the show spanning-tree output show multiple root ports?
A: In a single‑switch environment the output can be confusing. The switch lists all interfaces that could become root ports if a better bridge appears. Focus on the “Root Bridge” line for the actual root Small thing, real impact..

Q: Is there a way to automate these steps?
A: Absolutely. You can write a simple TCL or Python script that pushes the configuration via telnet or ssh. It’s a great next‑step once you’re comfortable typing the commands manually Practical, not theoretical..


That’s it. The real power of this lab isn’t just the commands; it’s the habit of checking, verifying, and documenting each change. 2 module 07” experience—from the first login to the final save. In practice, do that, and you’ll find yourself configuring real switches with the same confidence you just built in a virtual sandbox. So you’ve just walked through the entire “live virtual machine lab 7. Happy labbing!

7. Wrap‑Up Checklist – What Should Be Visible When You’re Done?

Item Command Expected Result
VLANs created show vlan brief VLAN 10, 20, 30 listed with the correct port assignments
Trunk operational show interfaces trunk Trunk port shows Encapsulation 802.1Q, native VLAN 1, and the list of allowed VLANs (10‑30)
Port‑security enforced show port-security interface <intf> Maximum 1, violation mode shutdown, sticky MAC address learned
Spanning‑Tree topology show spanning-tree Switch is the Root Bridge (Bridge ID = 32768.<MAC>), designated ports are the uplink and access ports, no blocked ports
Inter‑VLAN routing (if configured) show ip route Routes for VLAN‑10, VLAN‑20, VLAN‑30 networks appear, next‑hop points to the SVI IPs
IP connectivity ping <remote‑IP> from each host Successful replies (0% loss) for hosts in the same VLAN and across VLANs (if routing is enabled)
Configuration saved show startup-config All of the above settings appear in the saved file

You'll probably want to bookmark this section Practical, not theoretical..

If every row checks out, you’ve built a fully functional, documented, and resilient Layer‑2 (or Layer‑3) environment that mirrors a production edge switch.


8. Next Steps – Extending the Lab

  1. Introduce a Second Switch – Deploy another virtual switch, connect it with a trunk, and re‑run the spanning‑tree checks. This will expose you to root‑bridge elections, BPDU guard, and portfast interactions.
  2. Add a DHCP Server – Configure a DHCP pool on a router or a Layer‑3 switch, then verify that hosts obtain IP addresses automatically across VLANs.
  3. Implement ACLs – Create standard or extended ACLs on the VLAN interfaces to restrict inter‑VLAN traffic, then test with ping and traceroute.
  4. Play with STP Variants – Switch the mode from PVST+ to RSTP or MST and observe the convergence times after intentionally creating a loop.
  5. Automate with Ansible – Write a simple playbook that pushes the entire configuration to the switch via the network_cli connection plugin. This exercise bridges the gap between manual CLI work and real‑world network automation.

9. Common Pitfalls and How to Avoid Them

Symptom Likely Cause Fix
Hosts cannot ping each other even though they’re on the same VLAN Access ports assigned to the wrong VLAN or VLAN not allowed on the trunk Verify switchport access vlan X on each port and switchport trunk allowed vlan … on the trunk
show spanning‑tree shows a blocking port that should be forwarding BPDU guard or portfast misconfiguration on a non‑edge port Remove spanning-tree portfast from trunk ports and ensure BPDU guard is only on true edge ports
Port‑security shuts the interface down immediately after a host is connected Sticky MAC not yet learned, or a second device plugged into the same port Either pre‑populate the sticky MAC with switchport port‑security mac-address <MAC> or allow two MACs (maximum 2) while you test
After a reboot the configuration is gone write memory or copy running-config startup-config was never executed Always finish the lab with a write memory command; double‑check with show startup-config
Wireshark shows untagged frames on a trunk port Trunk encapsulation set to dot1q on one side but none on the other Re‑run switchport mode trunk and switchport trunk encapsulation dot1q on both ends of the link

10. Conclusion

Lab 7.That said, 2 – Module 07 is more than a checklist of commands; it’s a miniature replica of the daily workflow a network engineer performs on a production switch. By logging in, establishing a baseline, building VLANs, configuring trunks, tightening security, and finally verifying every step with the appropriate show commands, you develop a disciplined methodology that scales to real‑world deployments Turns out it matters..

The key takeaways are:

  • Document as you go. A simple text file with the exact show output becomes an invaluable reference for troubleshooting and for future labs.
  • Validate continuously. Use show vlan, show interfaces trunk, show port-security, and show spanning-tree after each major change rather than waiting until the end.
  • Save your work. The write memory command is the safety net that prevents hours of re‑configuration after a power cycle.
  • Iterate safely. Back up the original OVA, clone it before major experiments, and you’ll never be stuck waiting for a fresh lab environment.

When you finish this lab, you’ll have a solid grasp of how VLANs, trunking, port security, and spanning‑tree interact on a Cisco‑style switch. Also, that foundation will serve you whether you move on to multi‑switch topologies, Layer‑3 routing, or network automation. Keep the checklist handy, revisit the commands periodically, and you’ll find yourself configuring real switches with the same confidence you just built in this virtual sandbox.

Happy networking!
